In this post, you’ll find the details needed to wire up a set of Seymour Duncan 78 humbucker pickups. This configuration is fairly straightforward. There is one master volume and one master tone. Both of these pots are 500K ohms. The selector is a standard three-way blade switch, as found in a Fender Telecaster. As with all Seymour Duncan four-wire humbuckers, the black wire is the “hot,” the green wire goes to the ground, and the red & white wires are soldered together.
- Bridge Pickup: Seymour Duncan 78
- Neck Pickup: Seymour Duncan 78
- 1 X Volume – 500K
- 1 X Tone – 500K
- Standard 3-way blade switch
